Section 3: Configuration Menu

2/2013

61

51303 Rev. 1

4.4.4. METHOD 2, CONTINUED

13. Press the

ADD ROW

button to add

additional data to the end of the string.

14. Touch the empty

DATA TYPE

box.

15. Select the data item required.
16. Select the Scale, if this data is required also.

17. Press the

SAVE CHANGES

button when

any changes are made otherwise the
changes will be lost.

 Select

BACK: CONFIGURE COM1

to

return to the Configure COM1 menu.

18. Select the

TOKENS

menu.





19. Touch the screen data box to the right of

POLL

to select the available polling

character for the demand mode.
