Cell fail error codes, Type: xx cell: x – Fairbanks FB2550 DAT SERIES DRIVER ACCESS TERMINAL User Manual
Page 124
Section 6: Service & Maintenance
2/2013
124
51303 Rev. 1
7.3. CELL FAIL ERROR CODES
The error condition of Cell Fail appears on the display when a condition exists to
prevent proper weighing. Underneath the Cell Fail error in a small display font is the
words:
Type: xx Cell: x
.
This posts the error type the indicator identifies and the load cell which exhibits this
problem or the problem area.
TYPE ERROR
CODE
DESCRIPTION
1
Cell Zero Error
2
Cell Section Error
4
Cell Motion Error
8
Cell Calibration Error
10
Cell Out of Range Error
20
SSC Communication Error
40 Old
Revision
Board
