Section 2: Getting Started
2/2013 11 51303 Rev. 1
1.3. SPECIFICATIONS
Enclosure NEMA 4 Stainless Steel
BIOS Award™ Software 
RAM 1 GB
Disk Storage 8 GB
Operating System Windows XP Professional Embedded
Temperature
Operating Range
Storage Range
14°F to 104°F, (–10°C to 40°C).
Serial Outputs Up to 12 serial ports and 4 built-in USB ports. The USB port on the
Multi-Function board is dedicated for a keyboard only.
Digital I/O Up to 28 I/O
Ethernet Interface PCI 10/100 Mbps Ethernet Complies with IEEE 802.3x Standards
Display 7” Diagonal Touch Screen LCD Color
Scale Interface Options • Intalogix Technology
─ Intalogix Power Supply and Communications ( 30916 )
─ Scale Interface Controller ( 30918 )
• Analog Technology.
─ A/D Convertor Load Cell Interface ( 31079 )
 Up to sixteen (16) 1000 Ω or eight (8) 350 Ω cells.
Accessories • Serial Interface ( 30921 ), including:
– RS232 – RS-485 – 20mA
• 4-20mA ( 30919 )
• Mini keyboard ( 25498 )
─ USB – 87 key
• Keyboard ( 31036 )
─ USB – 104 key
• SVP/ Uninterruptible Power Supply (UPS) ( 15892 )
─ 500 VA Rating
• Fieldbus Gateway
– PROFIBUS-DP (30922) – DeviceNet (30923)
– ControlNet (30924) – MODBUS-TCP (30925)
Power Requirements 100 - 130 VAC @ 12A @ 60 Hz +/- 2 Hz
– Separate and dedicated circuit.
– Neutral to Ground voltage should be < 0.2 VAC
– One Amp (1A) is typical. Twelve Amps (12A) is a fully
equipped model.
ETL Listed  Conforms to UL STD 60950-1.
 CAN/CSA C 22.2 NO.60950-1-03.
Approvals
 CC# 10-089
 MC# AM-5805
