Configurationandparameter
settingsforEtherNet/IP
17.5. Applications object
The valve terminal parameters can be set via the following objects:
Object Class Instance Attributes Access Length
(byte)
Range Default Brief description
Inputs 8 1 ... 36 3 Get 1 0 ... 0 x FF Reads inputs via
Assembly or Class 8
Valves 9 1 ... 27 3 Get/Set 1 0 ... 0 x FF Switches valves via
Assembly or Class 9
Fault
Action
9 1 ... 27 5 Get/Set 1 0 ... 0 x
FF
0 x FF Action in case of fault
or offline per output
0: Fault Value
(Default in Fault
Value attribute 6)
1: Hold last state
Fault
Value
9 1 ... 27 6 Get/Set 1 0 ... 0 x
FF
0 x 00
Factory ID 150 1 1 Get 4 Bürkert ident number
Factory
Serial
150 1 2 Get 4 Bürkert serial number
Input
mode
151 1 1 Get/Set 1 0 ... 3 0:
without
EME
1: with
EME
0: no inputs
1: normal inputs
2: shifted inputs
3: halved inputs
Input filter 151 1 2 Get/Set 1 0 ... 1 1 0: Filter Off
1: Filter ON
In the Fault Action and Fault Value configuration the Instance of each subsequent RIO node starts with the offset
of 3 (3 x 8 = 24 valves per island possible).
Example:
Fault Action RIO 1 --> Instance 4…6
Fault Value RIO 2 --> Instance 7…9
