Configurationandparameter
settingsforPROFIBUSDP
Extension terminal 2 with 8 valves (outputs) and 16 repeaters (inputs)
• Address 2 (extension terminal 2 always has the address 2)
• The valves 1-8 are assigned to outputs (PAA) byte 16 in the process image.
• The repeaters 1-16 are assigned to inputs (PAE) bytes 22+23 in the process image.
• Mode: Normal input mode
• Input filter active
DIP switch extension terminal 2
1 2 3 4 5 6 7 8 9 10 11 12
OFF ON OFF ON OFF OFF ON OFF ON OFF ON OFF
User parameter byte 11 User_Prm_Data 55 hex
Configuration
Byte No. (slot) 1* (0)** 2 (1) 3 (2) 4 (3) 5 (4) 6 (5) 7 (6) 8 (7)
Identification in Hex
(Dec) 11 (017) 20 (032) 11 (017) 20 (032) 11 (017) 20 (032) 11 (017) 20 (032)
Process image output
(PAA) 30 12 15 16
Process image input
(PAE) 15+16 20+21 17+18 22+23
Main terminal Extension terminal 0 Extension terminal 1 Extension terminal 2
* Standard
** Siemens
