45
Ext_Diag_Data (device-related diagnosis 10 or 14 bytes)
7 (6) Header byte (Length of the device-related diagnosis 10 or 14 bytes)
Diagnosis of the main terminal (HI)
8 (7) 0 0 0 0 0 0 0 HI: 24 V out
Parameterization and configuration error (see Section “9.7. Configuration and parameterization errors” )
9 (8) Configuration error number Parameterization error number
Diagnosis of extension terminal (EI)
10 (9) EI7: 24V out EI6: 24V out EI5: 24V out EI4: 24V out EI3: 24V
out EI2: 24V out EI1: 24V out EI0: 24V out
11 (10) EI7: NOK EI6: NOK EI5: NOK EI4: NOK EI3: NOK EI2: NOK EI1: NOK EI0: NOK
12 (11) EI7: Config EI6: Config EI5: Config EI4: Config EI3: Config EI2: Config EI1: Config EI0: Config
Switch positions of extension terminal (EI)
13 (12) EI0: DIP -8 EI0: DIP -7 EI0: DIP -6 EI0: DIP -5 EI0: DIP -4 EI0: DIP -11 EI0: DIP -10 EI0: DIP -9
14 (13) EI1: DIP -8 EI1: DIP -7 EI1: DIP -6 EI1: DIP -5 EI1: DIP -4 EI1: DIP -11 EI1: DIP -10 EI1: DIP -9
15 (14) EI2: DIP -8 EI2: DIP -7 EI2: DIP -6 EI2: DIP -5 EI2: DIP -4 EI2: DIP -11 EI2: DIP -10 EI2: DIP -9
16 (15) EI3: DIP -8 EI3: DIP -7 EI3: DIP -6 EI3: DIP -5 EI3: DIP -4 EI3: DIP -11 EI3: DIP -10 EI3: DIP -9
Only for 14 byte user diagnosis
17 (16) EI4: DIP -8 EI4: DIP -7 EI4: DIP -6 EI4: DIP -5 EI4: DIP -4 EI4: DIP -11 EI4: DIP -10 EI4: DIP -9
18 (17) EI5: DIP -8 EI5: DIP -7 EI5: DIP -6 EI5: DIP -5 EI5: DIP -4 EI5: DIP -11 EI5: DIP -10 EI5: DIP -9
19 (18) EI6: DIP -8 EI6: DIP -7 EI6: DIP -6 EI6: DIP -5 EI6: DIP -4 EI6: DIP -11 EI6: DIP -10 EI6: DIP -9
20 (19) EI7: DIP -8 EI7: DIP -7 EI7: DIP -6 EI7: DIP -5 EI7: DIP -4 EI7: DIP -11 EI7: DIP -10 EI7: DIP -9
HI main terminal on PROFIBUS-DP
Eln Extension terminal n on RIO bus (n = 0 to 7),
Example: EI0: DIP-4 extension terminal with address 0 switch 4
DIP-n DIP switch number of the corresponding extension terminal (to the right on bus module)
0:= OFF; 1:=ON
24 V Out 24 V output control voltage not present on corresponding valve terminal
0:=no error; 1:=error
NOK No signal from corresponding extension terminal on RIO bus
0:=no error; 1:=error
Config The corresponding extension terminal was configured by the master
0:=not configured; 1:=configured
9.7. Configuration and parameterization errors
Configuration error number Parameterization error number
1 Too many inputs (> 32) for one terminal 1 Too many inputs (> 32) for one terminal entered
2 Too many outputs (> 24) for one terminal 2 Too many outputs (> 24) for one terminal entered
3 Too few inputs for all terminals
(preset in parameterization telegram) 3 Parameterization telegram too long
4 Too few outputs for all terminals
(preset in parameterization telegram) 4 Too few outputs for all terminals
5 Wrong configuration byte 5
Configurationandparameter
settingsforPROFIBUSDP
english
Type 8640
