38
The following settings are permitted in the parameter telegram:
Byte No. Description
8 (0) DPV1_Status_1
9 (1) DPV1_Status_2
10 (2) DPV1_Status_3
11 (3) Input mode / Input filter / Diagnosis length See table below
12 (4) Number of bits inputs main terminal
13 (5) Number of bits outputs main terminal
14 (6) Number of bits inputs extension terminal 0 DIP switch on El 0: S1=OFF,
S2=OFF, S3=OFF
15 (7) Number of bits outputs extension terminal 0
16 (8) Number of bits inputs extension terminal 1 DIP switch on El 1: S1=ON,
S2=OFF, S3=OFF
17 (9) Number of bits outputs extension terminal 1
18 (10) Number of bits inputs extension terminal 2 DIP switch on El 2: S1=OFF,
S2=ON, S3=OFF
19 (11) Number of bits outputs extension terminal 2
20 (12) Number of bits inputs extension terminal 3 DIP switch on El 3: S1=ON,
S2=ON, S3=OFF
21 (13) Number of bits outputs extension terminal 3
22 (14) Number of bits inputs extension terminal 4 DIP switch on El 4: S1=OFF,
S2=OFF, S3=ON
23 (15) Number of bits outputs extension terminal 4
24 (16) Number of bits inputs extension terminal 5 DIP switch on El 5: S1=ON,
S2=OFF, S3=ON
25 (17) Number of bits outputs extension terminal 5
26 (18) Number of bits inputs extension terminal 6 DIP switch on El 6: S1=OFF,
S2=ON, S3=ON
27 (19) Number of bits outputs extension terminal 6
28 (20) Number of bits inputs extension terminal 7 DIP switch on El 7: S1=ON,
S2=ON, S3=ON
29 (21) Number of bits outputs extension terminal 7
Byte 11 (3)
Input mode Input filter OFF Input filter ON Input filter OFF
long diagnosis
Input filter ON
long diagnosis
no inputs 03 hex 43 hex 83 hex C3 hex
normal inputs 13 hex 53 hex 93 hex D3 hex
shifted inputs 23 hex 63 hex A3 hex E3 hex
halved inputs 33 hex 73 hex B3 hex F3 hex
For a description of the input modes and the input filter refer to Section “9.3. Mode inputs”.
Configurationandparameter
settingsforPROFIBUSDP
english
Type 8640
