Modulesforconventionalelectrical
connectiontechnology
Accessories
D-SUB plug 44-pin IP54 5 m cable Id.-No. 917 496
D-SUB plug 44-pin IP54 10 m cable Id.-No. 917 497
Colour code for D-SUB cable
The wires are soldered 1:1 to the D_SUB plug, i.e. wire 1 ws to Pin 1 D-SUB etc.
Pin/Wire Wire colour Code Pin/Wire Wire colour Code
1 white ws 23 white-red wsrt
2 brown br 24 brown-red brrt
3 green gn 25 white-black wssw
4 yellow ge 26 brown-black brsw
5 grey gr 27 grey-green grgn
6 pink rs 28 yellow-grey grgr
7 blue bl 29 pink-green rsgn
8 red rt 30 yellow-pink gers
9 black sw 31 green-blue gnbl
10 violet vi 32 yellow-blue gebl
11 grey-pink grrs 33 green-red gnrt
12 red-blue rtbl 34 yellow-red gert
13 white-green wsgn 35 green-black gnsw
14 brown-green brgn 36 yellow-black gesw
15 white-yellow wsge 37 grey-blue grbl
16 yellow-brown gebr 38 pink-blue rsbl
17 white-grey wsgr 39 grey-red grrt
18 grey-brown grbr 40 pink-red rsrt
19 white-pink wsrs 41 grey-black grsw
20 pink-brown rsbr 42 pink-black rssw
21 white-blue wsbl 43 blue-black blsw
22 brown-blue brbl 44 red-black rtsw
