Productdescription
5.3. Structure of the system
Each valve terminal is configured according to customer requirements. To ensure optimal performance for the task
in question a large range of electrical and fluid-related components is available.
Multiple connection module
Electric cable termination module
Terminal module for feedback indicator
Extension module for electrical inputs
Multipole feedback indicator inputs (initiators)
Electric cable
termination module
Multipole valve outputs
Field bus module
Electric base module
Pneumatic connection
module
Pneumatic base module
Pneumatic
connection module
Valves of type 6525 (5/2-way)
Figure 2: Example for the configuration of the modular electric valve terminal type 8640
