34
Example 5 - main terminal and 3 extension terminals Main terminal with 8 valves (outputs) and 16
repeaters (inputs)
• PROFIBUS-DP address 8
• The valves 1-8 are assigned to outputs (PAA) byte 30 in the process image.
• The repeaters 1-16 are assigned to inputs (PAE) bytes 15+16 in the process image.
• Mode: Normal input mode
• Input filter active
• RIO interface
DIP switch main terminal
1 2 3 4 5 6 7 8
OFF OFF OFF ON OFF OFF OFF OFF
Extension terminal 0 with 8 valves (outputs) and 16 repeaters (inputs)
• Address 0 (extension terminal 0 always has the address 0)
• The valves 1-8 are assigned to outputs (PAA) byte 12 in the process image.
• The repeaters 1-16 are assigned to inputs (PAE) bytes 20+21 in the process image.
• Mode: Normal input mode
• Input filter active
DIP switch extension terminal 0
1 2 3 4 5 6 7 8 9 10 11 12
OFF OFF OFF ON OFF OFF ON OFF ON OFF ON OFF
Extension terminal 1 with 8 valves (outputs) and 16 repeaters (inputs)
• Address 1 (extension terminal 1 always has the address 1)
• The valves 1-8 are assigned to outputs (PAA) byte 15 in the process image.
• The repeaters 1-16 are assigned to inputs (PAE) bytes 17+18 in the process image.
• Mode: Normal input mode
• Input filter active
DIP switch extension terminal 1
1 2 3 4 5 6 7 8 9 10 11 12
ON OFF OFF ON OFF OFF ON OFF ON OFF ON OFF
