SMX System MultiMatrix Switcher • SIS Configuration and Control
51
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Write input name (per plane)
EX2@
*
X!
,nameNI
}
X2@
Nmi
X!
,name
]
Assign a name to input
X!
.
Read input name
EX2@
*
X!
NI
}
name
]
Write output name (per plane)
EX2@
*
X#
,nameNO
}
X2@
Nmo
X#
,name
]
Assign a name to output
X#
.
Read output name
EX2@
*
X#
NO
}
name
]
NOTES:
•
If a preset (global or plane) is unassigned, its name is displayed [unassigned].
•
If a global preset is saved but not named, its default name is Preset
X1!
.
•
If a plane preset is saved but not named, its default name is Pln
X2@•
Pre
X1!
.
•
If you attempt to name or recall a preset that is not saved, or is unassigned, the unit responds with the error
message E11.
•
Putting a space in the name field sets the I/O and presets (global & plane) back to default.
Reset to Factory Defaults (Zap Commands)
Reset global presets and
names
E
ZG
}
Zpg
]
Clear all global presets and their
names.
Reset individual global presets
EX1!
ZG
}
Zpg
X1!]
Clear global preset
X1!
.
Reset individual plane presets
EX2@
*
X1!
ZG
}
X2@
Zpg
X1!]
Clear plane preset
X1!
.
Reset All RGB Delay to 0
seconds
E
ZD
}
Zpd
]
Reset RGB Delay to zero.
Reset RGB Delay entire plane
EX2@
ZD
}
X2@
Zpd
]
Reset RGB Delay to zero.
Reset all audio gains to 0 dB
E
ZA
}
Zpa
]
Reset all audio gains to zero.
Reset audio gains to 0 dB for
entire plane
EX2@
ZA
}
X2@
Zpa
]
Reset all audio gains to zero.
Reset all audio volume to 100%
E
ZV
}
Zpv
]
Reset all volume to 100%.
Reset all audio volume to 100%
for entire plane
EX2@
ZV
}
X2@
Zpv
]
Reset all volume to 100%.
Unmute RGB/Audio (all mutes)
E
ZZ
}
Zpz
]
Unmute RGB/Audio (per plane)
EX2@
ZZ
}
X2@
Zpz
]
Reset switcher
E
ZXXX
}
Zpx
]
Clear all ties and presets and reset
the SMX to factory defaults.
Reset flash memory
E
ZFFF
}
Zpf
]
Reset flash memory (reset
user-supplied files).
Absolute system reset
E
ZQQQ
}
Zpq
]
Reset IP address to
192.168.254.254 and subnet mask
to 255.255.0.0.
Reset all device settings and
delete files
E
ZY
}
Zpy
]
Reset device and delete all files.
NOTE:
E
ZY reset excludes IP settings (IP address, subnet mask, gateway address, unit name, DHCP settings
and port mapping [Telnet, web, or direct access]) in order to preserve communications with the device. This reset is
recommended after a firmware update.
NOTES:
X!
= Input number
01 - <maximum number of inputs>
X#
= Output number
01 - <maximum number of outputs>
X1!
= Global or plane preset
1 - 32 = global
1 - 10 = plane
X2@
= Plane address
00 - 15 = 16 planes
90 - 99 = virtual planes (10 planes)
