6.10.3 iRIS Sensor Configuration
Once the Vaisala has been configured (as shown in Section 6.10.2 above), the iRIS can be then be
configured with the following sensor settings:
Once the six sensors have been configured, the main
sensor configuration menu should look like this.
Sensor 3 is the Vaisala WXT5x0 air
temperature and Sensor 9 is the iRIS internal
temperature which is not enabled in this
example.
A pre-configured iRIS configuration file for
the WXT5x0 instrument is available from the
iQuest website. This can be sent to the logger
using iLink’s configuration tool described in
the next section.
* Sensor Cfg
0 Exit
1 Sen1 [15:SDI 0,1]Wind Dir
2 Sen2 [15:SDI 0,2]Wind Spd
3 Sen3 [15:SDI 0,3]Air Temp
4 Sen4 [15:SDI 0,4]Humidity
5 Sen5 [15:SDI 0,5]Barometer
6 Sen6 [13:Loc1605]Rainfall
7 Batt [60 min]
8 Supp [60 min]
9 Temp [Dis]
>
* Sensor 1 Cfg
(Now: 93.000)
0 Exit
1 Source [15: SDI 0,1]
2 Name [Wind Dir]
3 Mode [Scalar Avg+Min+Max]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [1]
7 Log Rate [5 min]
8 Alarms
9 Data * Sensor 2 Cfg
(Now: 0.665)
0 Exit
1 Source [15: SDI 0,2]
2 Name [Wind Spd]
3 Mode [Period Avg+Min+Max]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [10]
7 Log Rate [5 min]
8 Alarms
9 Data
* Sensor 5 Cfg
(Now: 1019.400)
0 Exit
1 Source [15: SDI 0,5]
2 Name [Barometer]
3 Mode [Instant]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [10]
7 Log Rate [5 min]
8 Alarms
9 Data
* Sensor 3 Cfg
(Now: 22.800)
0 Exit
1 Source [15: SDI 0,3]
2 Name [Air Temp]
3 Mode [Instant]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [10]
7 Log Rate [5 min]
8 Alarms
9 Data * Sensor 4 Cfg
(Now: 39.000)
0 Exit
1 Source [15: SDI 0,4]
2 Name [Humidity]
3 Mode [Instant]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [10]
7 Log Rate [5 min]
8 Alarms
9 Data
* Sensor 6 Cfg
(Now: 0.000)
0 Exit
1 Source [13: Loc1605]
2 Name [Rainfall]
3 Mode [Instant]
4 Mult [ 1.00000]
5 Offset [ 0.00000]
6 Log Mult [100]
7 Log Rate [5 min]
8 Alarms
9 Data
