Option 4
When this option is selected you will be prompted to enter an IP address and then a UDP or TCP port to use
for Socket A. The iRIS uses Socket A for ASCII communication via UDP if it is a GPRS model.
> Socket A IP=
Enter the remote IP address you want to have ASCII messages delivered to/from by default. Next, you will
be prompted to enter a port number to use for socket A.
> Socket A Port=
Enter a non-zero port number.
The 3G and CDMA-1X variants do not use this socket at the present time. In these cases the settings
are ignored and should be set to the same IP address and port as Socket B below.
Option 5
When this option is selected you will be prompted to enter an IP address and then a UDP or TCP port to use
for socket B. Socket B is the socket that is used by the iRIS for iQuest protocol (binary) communication. This
is the destination IP address used for unsolicited binary calls and must be configured.
> Socket B IP=
Enter the remote IP address that you will connect to. Next, you will be prompted to enter a port number to
use for socket B.
> Socket B Port=
Enter the remote port number that you want to have iQuest protocol messages delivered to by default (e.g.
7777). For the iQuest Data Network use port 7779 or port 7780 for GPRS / CDMA-1X models and port 7781
for 3G models unless advised otherwise by iQuest.
Option 6
Select this option to display the IP Acceptance set-up menu.
Option 7
Select this option to display the GPRS/3G/CDMA-1XSchedule configuration menu.
Option 8
Select this option to display the current network settings (GPRS/3G only) or the wireless module
identification parameters for CDMA. Example information for both GPRS and CDMA variants is as follows:
GPRS / 3G
IMSI: 530011100721422
IMEI: 355435000001213
L/C: 0005,143F
LOC: 5
TWR: 18
ANT: 3
RSSI: 19,00
IMSI: International Mobile Subscriber Information. This is derived from the SIM card
IMEI: International Mobile Equipment Identifier. This is stored in the GPRS module by iQuest during initial
calibration and setup of the iRIS and uniquely identifies the hardware by manufacturer and serial
number.
L/C:
Location/Cell string. This is the exact cell identification string as received from the GPRS module.
This is processed by the iRIS, which extracts and displays in the information in the next three
parameters. The exact nature of these may vary depending on the country and network provider.
