Page 47
41
iQuest (NZ) Ltd - PO Box 15169, Hamilton, New Zealand Tel: +64 7 857-0810 Fax: +64 7 857-0811 Email: [email protected]
System Status 4 Screen (Level 1)
The System Status 4 screen is also always available, no matter what level of access has been selected.
The information shown on this screen includes the current status of the digital inputs and outputs (0=OFF,
1=ON). This screen shows the current SOD and EOD pointer values.
Logging Control Screen (only accessible when logged in)
The Logging Control screen is a special screen that is only available on level 1 when a user is logged in. It
can be used to temporarily disable logging when the logged in user is making changes to or tests with
sensors and does not want to have the data logged. It is reached by pressing the + key from Status Screen
4. Use the Enter key to toggle logging on or off. If the logging is disabled, it is always re-enabled
automatically when the user logs out, either manually or on inactivity timeout.
Use the – or + keys to switch the logging on or off. Pressing the
top-level Welcome (System Status 1) screen.
Main Menu Screen (Level 2)
The Main Menu screen is used to select which type of information you want to look at.
5.2.6 Sensor Related Screens
Sensor Status Screen (Level 3)
This screen provides an overview of each sensor.
Line 1 indicates sensor ID, data source and its composite status including:
‘.’ if sensor is enabled
‘:’ if sensor and alarm(s) are enabled
‘*’ if sensor and alarm(s) are enabled and alarm(s) currently active
Line 2 indicates the raw input value.
Line 3 indicates the scaled (engineering unit’s) value.
Line 4 indicates the last logged value.
MAIN MENU
>Sensors
Totals
Comms
1: Bat Volt
Input: 1257
Scaled: 12.57
Logged: 12.62
+/-
Move down/up through menu
Enter
Select menu item
Alt Enter
Move up to System Status 1 screen
+/-
Move forwards/backwards through sensors
Enter
Drill down to Sensor Menu screen
Alt Enter
Move up to Main Menu screen
DI1:0 DI2:1
DO1:1 DO2:0
SOD Ptr: 177104
EOD Ptr: 177336
-
Move back to System Status 3 screen
+
Move to Logging Control screen if logged in. Unused otherwise.
Enter
Move down to Main Menu screen
Alt Enter
Log in (If PIN code <> 0), otherwise unused
LOGGING CONTROL
Use Enter key to
Enable/disable.
=> Enabled
-
Move back to System Status 4 screen
+
Unused
Enter
Toggle logging on or off
Alt Enter
Unused
