4.4 Terminal Menus
4.4.1 Main Menu (Level 1)
Throughout all the terminal menus, there are two common entry codes.

Menu option 0 (zero) always returns you to the level above your current position.
 Entering “r” or “R” when in a menu being prompted for an option will refresh the menu without
selecting anything. This can be useful over a UDP terminal session where it is possible a packet may
be lost and you are unsure which menu is currently selected.
When a terminal session has been established with the iRIS through the RS232 port or UDP socket A, you
will be presented with the main menu. To make a menu selection, type a number followed by .
Invalid menu selections will result in the display of an error message on the terminal. The current value of
each settable item is enclosed in square braces e.g. [1234].
Level1
Level2 Level3 Level4 Level5
Main Menu
Comms Cfg
GPRS/3G/CDMA-1X Cfg
IP Acceptance Cfg
Schedule Cfg
Network Info
RS232 Configuration
Phone List
Sensor Selection
Sensor Cfg
Alarm Selection
Alarm Cfg
Output Selection
Output Cfg
Date/Time Cfg
Miscellaneous
[Voice] or [Camera] (options)
Figure 11 - Terminal Menu Structure
All configuration examples shown in the following sections are for a GPRS version iRIS350V.
