MultiPump – Slave Pump Control
10. After saving your motor horsepower, press the EXIT key. Use
the down arrow until you highlight the group 15 “XDUCER
VARIABLES”, then press EDIT.
11. Press the down arrow until parameter 1502 TRANSDUCER
MAX is highlighted, then press EDIT. Default pressure
transducer setting is 300 psi. Adjust this based on your
maximum rating for a new transducer. NOTE: CentriPro
provides a 0 -300 psi transducer as standard. Select the
appropriate range, then press SAVE. If no changes are
necessary, press CANCEL.
12. Use the down arrow to highlight 1503 “TRANSDUCER MIN”
0.0, then press EDIT. Default should be 0 psi. Press CANCEL
to advance to the next step. If this group needs to be
changed based on another type of transducer value, press
SAVE to store.
13. Use the down arrow to highlight 1506 “SENSOR MIN”,
then press EDIT. Use the up arrow until the “TUNE” value is
displayed, press the SAVE key. This provides the transducer
a tuned value of 0 (ZERO) psi. NOTE: Make sure that your
transducer is wired to the Aquavar but free from any
pressure in the system. The transducer must be exposed
to 0 psi when this step is performed. Press the SAVE key to
tune your transducer.
EXIT SEL
REM
15 XDUCER VARIABLES
16 REFERENCE SELECT
18 RELAY OUTPUTS
19 ANALOG OUTPUTS
21 REGULATE
PAR GROUPS 15
EXIT EDIT
REM PARAMETERS
1501 TRANSDUCER UNIT
1502 TRANSDUCER MAX
300.0
1503 TRANSDUCER MIN
1504 SENSOR
EXIT EDIT
REM PARAMETERS
1501 TRANSDUCER UNIT
1502 TRANSDUCER MAX
1503 TRANSDUCER MIN
0.0
1504 SENSOR
PROGRAMMING
EXIT EDIT
REM PARAMETERS
1504 SENSOR
1505 K-DP FLOW METER
1506 SENSOR MIN
TUNE
CANCEL SAVE
REM PAR EDIT
1506 SENSOR MIN
4 mA
CANCEL SAVE
REM PAR EDIT
1506 SENSOR MIN
TUNED VALUE
