91
MultiPump – Constant Pressure Control
6. Use down arrow until group parameter 1104 “MOTOR
NOM VOLTAGE” is highlighted, then press EDIT. Use the
arrows to enter your motors nameplate voltage, then press
the SAVE key.
7. Use the down arrow until group parameter 1105 “MOTOR
NOM CURRENT” is highlighted, then press EDIT. Using the
arrows, enter your motor’s maximum allowed amp draw
at full speed, or Service Factor Amps. NOTE: Enter motors
service factor from nameplate or motor manual. Once you
have entered the amps, press the SAVE key.
8. Use down arrow until you highlight group parameter 1107
“MOTOR NOM RPM”, then press the EDIT key. Use arrows
to enter the RPM from the motor nameplate, default is 3550
RPM. Press the SAVE key to store setting.
9. Use down arrow until you highlight group parameter 1108
“MOTOR NOM POW”, then press the EDIT key. Use arrows to
enter the motors Horsepower rating from nameplate, then
press the SAVE key.
10. After saving your motor horsepower, press the EXIT key. Use
the down arrow until you highlight the Group 15 “XDUCER
VARIABLES”, then press SEL.
11. Press the down arrow until parameter 1502 “TRANSDUCER
MAX” is highlighted, then press EDIT. Default pressure
transducer setting is 300 psi. Adjust this based on your
maximum rating for a new transducer. NOTE: CentriPro
provides a 0-300 psi transducer as standard. Always check
the maximum range of your transducer before proceeding.
Select the appropriate range, then press SAVE. If no changes
are necessary, press CANCEL.
EXIT EDIT
REM PARAMETERS
1101 LANGUAGE
1102 APPLIC MACRO
1104 MOTOR NOM VOLT
1105 MOTOR NOM CURR
EXIT EDIT
REM PARAMETERS
1104 MOTOR NOM VOLT
1105 MOTOR NOM CURR
1106 MOTOR NOM FREQ
1107 MOTOR NOM RPM
3550 RPM
EXIT EDIT
REM PARAMETERS
1105 MOTOR NOM CURR
1106 MOTOR NOM FREQ
1107 MOTOR NOM RPM
1108 MOTOR NOM POW
1.0 HP
EXIT EDIT
REM PARAMETERS
1101 LANGUAGE
1102 APPLIC MACRO
1104 MOTOR NOM VOLT
1105 MOTOR NOM CURR
3.5A
EXIT SEL
REM PAR GROUPS 15
11 START-UP DATA
12 START/STOP
13 RAMPS/WINDOWS
14 SPD LIM/STRT LEVL
15 XDUCER VARIABLES
PROGRAMMING
EXIT EDIT
REM PARAMETERS
1501 TRANSDUCER UNIT
1502 TRANSDUCER MAX
300.0 PSI
1503 TRANSDUCER MIN
1504 SENSOR
