5. Press UP/DOWN to select a new value / edit the parameter value. (Pressing both keys at

the same time sets a parameter to its default value.)

6. Press SAVE to save the new parameter value. (If the new value is the default value, the pa-

rameter will no longer appear on the Changed Parameters listing.)

Par Backup Mode
The Control Panel can store a full set of drive parameters. If two sets of parameters are de-
fined, both are copied and transferred when using this feature.
The Par Backup Mode has three functions:

• Upload to Panel – Copies all parameters from the drive to the Control Panel. The Control

Panel memory is nonvolatile and does not depend on the panel’s battery.

• Restore All (Download To Drive All) – Restores the full parameter set(s) from the Control

Panel to the drive. Use this option to restore a drive or to configure identical drives. Drive

must be in local mode.

NOTE! The Restore All function writes all parameters to the drive, including motor param-
eters. Only use this function to restore a drive or to transfer parameters to systems that are
identical to the original system.

• Download Application – Copies partial parameter set(s) from the Control Panel to a drive.

The partial set does not include internal motor parameters. Use this option to transfer pa-
rameters to systems that use similar configurations - the drive and motor sizes do not need
to be the same.

1. Select COPY in the Main Menu.
2. Press UP/DOWN to step to the desired option.
3. Press SAVE. The parameter set is transferred as directed. During the transfer, the

display shows the transfer status as a percent of completion.

4. Press EXIT to step back to the Output Mode.

Clock Set Mode
Use the Clock Set Mode to:

• Enable/disable the clock function.
• Set date and time.
• Select display format.

1. Select CLOCK SET in the Main Menu.
2. Press UP/DOWN to step to the desired option.
3. Press EDIT.
4. Press UP/DOWN to select the desired setting.
5. Press SAVE to save setting.
