Xylem IM167 R8 Aquavar CPC (Centrifugal Pump Control) - Manual (Page 131)

131
Cable Sizing/Ratings
208…240 Volt Drives
The following tables provide current, horsepower, frame size and recommended cable sizes
for the Aquavar CPC.
CENTRIPRO AQUAVAR CPC
NEMA 1 Full NORMAL
Frame
Output Input
Voltage Phase Base Load DUTY
Size 2
Cable Size Cable Size
Model Amps HORSEPOWER Min. AWG 1 Min. AWG 1
CPC20171 8.5 2 R1 14 10
CPC20241 12 3 R2 12 8
CPC20311 15.5 5 R2 12 8
CPC20461 23 7.5 R3 10 6
CPC20591 29.5 10 R3 8 4
230 1 CPC20881 44.0 15 R4 6 2
CPC21141 57.0 20 R4 4 1/0
CPC21431 71.5 25 R6 3 3/0
CPC21781 89.0 30 R6 2 4/0
CPC22211 110.5 40 R6 1/0 300MCM
CPC22481 124.0 50 R6 2/0 350MCM
CPC20121 11.8 3 R1 14 14
CPC20171 16.7 5 R1 10 10
CPC20241 24.2 7.5 R2 8 8
CPC20311 30.8 10 R2 8 8
CPC20461 46.2 15 R3 6 6
CPC20591 59.4 20 R3 4 4
230 3 CPC20751 74.8 25 R4 3 3
CPC20881 88.0 30 R4 2 2
CPC21141 114.0 40 R4 1/0 1/0
CPC21431 143.0 50 R6 3/0 3/0
CPC21781 178.0 60 R6 4/0 4/0
CPC22211 221.0 75 R6 300MCM 300MCM
CPC22481 248.0 100 R6 350MCM 350MCM
(1) Recommended AWG Size based on NEC table 310.16, 40º C ambient, 90º C, UL type copper wire. For other
wire sizes or types, consult local, state or NEC codes.
(2) Frame sizes R7 and R8, the Aquavar CPC will have multiple conductor terminals for each phase. Consult
technical section (CABLE TERMINALS).
TECHNICAL DATA
