61
Defaults
Group
Reference Range
Description
Single Synch- Multi- Constant Speed
16 Select Pump ronous Control Slave Control
1601 SP1/SP2 Select Defines the source from which Ref 1 Ref 1 Ref 1 Ref 1 Ref 1
the drive reads the signal that
selects the setpoint.
Reference 1 Reference 1 (set point 1) is
(Default) being used only.
DI4 Digital Input 4 selects set point 1
or set point 2. 0pen = Set Point
1, Closed = Set Point 2.
Fieldbus The set point is sent via Fieldbus
control word.
1602 Set Point 1 Select Selects the signal source for Keypad Keypad Keypad Keypad Keypad
Reference1 (set point #1).
Keypad The set point is selected from
(Default) the keypad.
Analog Input The set point is selected by an
Speed Control analog input (AI1).
Fieldbus The set point is selected via
Fieldbus control word.
1603 Set Point 2 Select Selects the signal source for Keypad Keypad Keypad Keypad Keypad
Reference1 (set point #2).
Keypad The set point is selected from
(Default) the keypad.
AI 1 The set point is selected by an
analog input (AI1).
Fieldbus The set point is selected via
Fieldbus control word.
1604 AI 1 Minimum Defines the minimum value for 4-20 4-20 4-20 4-20 4-20
analog input AI1. mA mA mA mA mA
0-10 VDC A 0VDC signal will activate a
Sensor Failure fault function
unless 24.01 and 24.02 are
disabled.
4 – 20 mA 4 mA is selected as the
(Default) minimum value.
Tuned Value Select tuned value after the tune
function has been completed.
This will select the tuned value
for the minimum value of AI1.
PARAMETER LISTINGS
