Xylem IM167 R8 Aquavar CPC (Centrifugal Pump Control) User Manual
Page 8
8
TYPICAL DRIVE LABEL
SW:
ACS550-U1-046A-2 ACS550-U1-046A-2
SW:
V.2.06B
V.2.06B
2053901277
2053901277
S/N
2053901277
S/N
2053901277
Input
3 PH 48…63
1 PH 48…63 Hz
Voltage (U1)
208…240 Vac
208…240 Vac
Current (11n)
46.2 A
46.2 A
Short Circuit
100 kAIC
100 kAIC
Output
3 PH 0…500 Hz
3 PH 0…500 Hz
Voltage (U2)
0…U1 Vac
0…U1 Vac
Current (12n)
46.2 A
22 A
Current (12hd)
30.8 A
Power (Pn)
15 HP
7.5 HP
Power (Phd)
ACS550-U1-046A-2
Made in USA of foreign parts
Mfg. Date: 31-October-2005
Orig. Firmware: V.2.06B
S/N
2053901277
C
US
UL
®
IND. CONT. EQ.
LISTED 45Y1
C
US
®
159339
206578
