140
Air Flow, 208…240 Volt Drives
The following table lists heat loss and air flow data for 208…240 Volt drives.
CENTRIPRO AQUAVAR CPC
NEMA 1 Full NORMAL
Frame Heat Loss Air
Voltage Phase Base Load DUTY
Size Flow
Model Amps HORSEPOWER Watts BTU/HR CFM
CPC20171 8.5 2 R1 161 551 26
CPC20241 12 3 R2 227 776 52
CPC20311 15.5 5 R2 285 373 52
CPC20461 23 7.5 R3 420 1434 79
CPC20591 29.5 10 R3 536 1829 79
230 1 CPC20881 44.0 15 R4 786 2685 165
CPC21141 57.0 20 R4 1014 3463 165
CPC21431 71.5 25 R6 1268 4431 238
CPC21781 89.0 30 R6 1575 5379 238
CPC22211 110.5 40 R6 1952 6666 238
CPC22481 124.0 50 R6 2189 7474 238
CPC20121 11.8 3 R1 116 404 26
CPC20171 16.7 5 R1 161 551 26
CPC20241 24.2 7.5 R2 227 776 52
CPC20311 30.8 10 R2 285 373 52
CPC20461 46.2 15 R3 420 1434 79
CPC20591 59.4 20 R3 536 1829 79
230 3 CPC20751 74.8 25 R4 671 2290 165
CPC20881 88.0 30 R4 786 2685 165
CPC21141 114.0 40 R4 1014 3463 165
CPC21431 143.0 50 R6 1268 4431 238
CPC21781 178.0 60 R6 1575 5379 238
CPC22211 221.0 75 R6 1952 6666 238
CPC22481 248.0 100 R6 2189 7474 238
TECHNICAL DATA
