104
Parameter Name Value/Range Note(s)
30.01 COMM NOT SELECTED No fieldbus communication
PROTOCOL (Default)
SELECT STD MODBUS Drive uses MODBUS protocol on the
standard RS485 port. Protocol settings
are in group 32.
EXT FBA The drive communicates with a fieldbus
adapter module in option slot 2 of the
drive. NOTE: When EXT. FBA is selected
parameter group 31 is unlocked.
Any parameter changes that are made using a Fieldbus control system must be saved to the
drive.
Parameter Name Value/Range Note(s)
10.04 PARAMETER DONE (Default) Parameters that are manually entered through
SAVE SAVE the keypad are automatically saved, only
parameters entered through a Fieldbus
connection must be saved. To save, select SAVE
and press the ENTER key.
Language
The Aquavar CPC system fully supports 3 languages; English(AM), French, and Spanish.
English(AM) refers to American English and is the default language. Units of power are in HP.
Parameter Name Value/Range Note(s)
11.01 LANGUAGE ENGLISH (AM) ENGLISH (AM) is the default setting.
ESPANOL
FRANCAIS
Locking
The AQUAVAR CPC has three levels of control panel (keypad) locking; LOCAL LOCK,
PARAMETER LOCK and SET POINT LOCK.
• PARAMETER LOCK - In parameter lock, parameters may be viewed, however they cannot
be changed. Starting, Stopping, set point changes and drive fault resets may still be
performed using the keypad. A valid password must be entered in parameter group 10.02.
• LOCAL LOCK - In local lock, starting and stopping, and setpoint changes are prevented.
Resetting of drive faults is still possible and ON and OFF control.
• SET POINT LOCK – When in the “ON“ position, the set-point cannot be changed from the
control panel. This prevents unwanted changes to Aquavar settings.
To change the drive parameters, including 10.03 LOCAL LOCK, the parameter lock must be
opened. To open the parameter lock, go to parameter 10.02 PASS CODE and scroll to the
number 66 and press ENTER. Parameter 10.01 PARAMETER LOCK will read OPEN.
NOTE: If power to the drive is lost [power failure, disconnect, etc…] parameter 10.01
PARAMETER LOCK will automatically reset to LOCKED.
FEATURES
