Xylem IM167 R8 Aquavar CPC (Centrifugal Pump Control) - Manual (Page 63)

63
Defaults
Group
Relay Range Description Single Synch- Multi- Constant Speed
18 Outputs Pump ronous Control Slave Control
1804 Relay RO2 Selects the AV status to be Run- Run- Run- Start Run-
Output indicated through relay output 2 ning ning ning Slave ning
(RO2). The relay energizes when
the status meets the setting.
Relay warnings are reset
automatically, faults must be
manually reset.
Not Sel The output is not used
Run (Default) The output indicates the drive
is running.
VFD Fault The drive has faulted
Low Water The secondary protection
warning or fault function has
been activated. DI4 is low for
the protection delay setting
(2404). Closed = normal,
Open = Secondary Protect fault
function is active.
Pump Protect The pump protection warning or
fault function has been activated.
Start Slave Used in multipump macro to
start slave pump only.
Stand by Drive is in sleep mode due to
no system demand.
1805 RO2 ON Delay 0…3600 s Defines the operation delay for 0 0 0 0 0
relay output RO2.
1806 RO2 OFF Delay 0…3600 s Defines the release delay for 0 0 0 0 0
relay output RO2.
1807 Relay RO3 Selects the AV status to be Not Not Not Not Not
Output indicated through relay output 3 Used Used Used Used Used
(RO3). The relay energizes when
the status meets the setting.
Relay warnings are reset
automatically, faults must be
manually reset.
Not Sel (default) The output is not used
Run The output indicates the drive is
running.
Ready The output indicates that power
is supplied to the drive and it is
awaiting a start command.
VFD Fault The drive has faulted
PARAMETER LISTINGS
