145
Ambient Conditions
The following table lists the AQUAVAR environmental requirements.
Ambient Environment Requirements
Installation Site
Storage and Transportation
in the protective package
• 0…1000 m (0…3,300 ft)
• 1000…2000 m (3,300…6,600 ft)
Altitude 1 if P
N
and I
2
derated 1% every
100 m above 1000 m
(300 ft above 3,300 ft).
Ambient • -15…40º C (5…104º F) -40…70º C (-40…158º F)
Temperature 2 • Max. 50º C (122º F) if P
N
and I
2
derated to 90%.
Relative humidity < 95% (non-condensing)
• No conductive dust allowed. Storage
• The ACS550 should be installed • No conductive dust allowed.
in clean air according to • Chemical gases: Class 1C2
Contamination enclosure classification. • Solid particles: Class 1S2
levels • Cooling air must be clean, free Transportation
(IEC 721-3-3) from corrosive materials and free • No conductive dust allowed.
from electrically conductive dust. • Chemical gases: Class 2C2
• Chemical gases: Class 3C2 • Solid particles: Class 2S2
• Solid particles: Class 3S2
• Mechanical conditions: Class 3M4 In accordance with ISTA-1A and 1B
Sinusoidal (IEC 60721-3-3) specifications.
Vibration • 2…9 Hz 3.0 mm (0.12 in)
• 9…200 Hz 10 m/s 2 (33 ft/s 2 )
Shock
Not allowed
Maximum 100 m/s 2 (330 ft/s 2 ),
(IEC 68-2-29) 11ms (36 ft)
• 76 cm (30 in), frame size R1
• 61cm (24 in), frame size R2
Free Fall
3 Not allowed
• 46 cm (18 in), frame size R3
• 31 cm (12 in), frame size R4
• 25 cm (10 in), frame size R5
• 15 cm (6 in), frame size R6
(1) Consult factory above 6600’ altitude.
(2) Derate drive one HP size from motor for higher temperatures (e.g. motor HP = 10 HP; use 15 HP Aquavar in
temperature up to 122º F).
(3) R7-R8 not allowed for free fall any distance.
TECHNICAL DATA
