57
Defaults
Group
Start/Stop Range Description
Single Synch- Multi- Constant Speed
12 Pump ronous Control Slave Control
1203 Test Run Automatic If selected and the drive has not
(continued) run for the test delay (1205) the
drive will start and run at 50%
of maximum speed (1401) for
20 seconds and shutdown.
Auto Restart 1202 must be on.
Manual Once manual is selected the Not Sel Not Sel Not Sel Not Sel Not Sel
drive will start and run at test
speed (1204) for 20 seconds
and shutdown. Once the
manual test is complete this
parameter will return to
“Not Sel”.
1204 Test Speed % (FL) 0...100% Selects the speed the test runs 25% 25% 25% 25% 25%
at in manual test mode (1203).
1205 Test Run Delay 0...3600 Hr Selects how long after the drive 1000 1000 1000 1000 1000
is idle before it will do a test run.
1206 Motor Jog Jogs motor for 10 sec @ 60 RPM Disabled Disabled Disabled Disabled Disabled
to check for motor rotation.
1209 Manual Disabled Drive will run at constant speed
Override (Default) as set in Parameter 1210 when
enabled and contact DI5 is active.
1210 Override 0-60 Hz Sets motor speed when manual
Freq override is active.
Group Ramps/
Range Description
Single Synch- Multi- Constant Speed
13 Windows Pump ronous Control Slave Control
1301 Ramp 1 Fast Accel 0…1800 sec Defines the fast acceleration time. 5 5 5 5 5
1302 Ramp 2 Fast Decel 0…1800 sec Defines the fast deceleration time. 5 5 5 5 5
1303 Ramp 3 Slow Accel 0…1800 sec Defines the slow acceleration time. 60 60 60 60 60
1304 Ramp 4 Slow Decel 0…1800 sec Defines the slow deceleration time. 60 60 60 60 60
1305 Ramp Hysteresis 0…100 % Per cent of window set aside 80 80 80 80 80
for hysteresis error.
1306 Reg Window 0…100 % Window around the set point
which the control algorithm 8 8 8 8 8
operates.
Group Spd Lim/
Range Description
Single Synch- Multi- Constant Speed
14 Strt Lvl Pump ronous Control Slave Control
1401 Maximum Minimum Defines the allowable maxi- 60 60 60 60 60
Frequency/Speed Frequency… mum speed. Default setting
60 Hz is parameter 1106 Motor Nom
Freq. (May want to show RPM
or HZ.)
PARAMETER LISTINGS
