Defaults
Group VFD Signals
Range Description
Single Synch- Multi- Constant Speed
01 ➀ Pump ronous Control Slave Control
0101 Motor 0.0...500.0 Hz Calculated VFD output
Frequency frequency, Hz
0102 Motor Current 0...2.0*I
2hd
Measured Motor Current, A
0103 Motor Power -2...2*P
hd
Motor Power, kW
0104 DC Bus Voltage 0…2.5*V
dn
Measured intermediate circuit
voltage, V
0105 Motor Voltage 0…2.0*V
dn
Calculated motor voltage, V
0106 Drive Temp 0…150º C VFD Temp, Deg C
0107 VFD On Time 0…9999h Elapsed time counter; runs
when the drive is powered, Hrs
(since last reset). Re-settable by
parameter 2605.
0108 Run Time 0…9999h Motor run time counter, Hrs
(since last reset). The counter
runs when the inverter
modulates. Re-settable by
parameter 2605.
0109 KWh Counter 0…9999kWh kWh counter, kWh (since last
reset). Re-settable by parameter
2605.
0110 DI6-1 Status 000000… Status of digital inputs.
111111 Example: 0000001=DI1 is on,
DI2-DI6 off
0111 AI1 0…100 % Value of analog input 1, %
0112 AI2 Trnsdcr Fdbk 0…100 % Value of analog input 2, %
0113 RO3-1 Status 000…111 Status of relay outputs.
Example: 001=RO1 is energized,
RO2 & RO3 are de-energized.
0114 AO1[mA] 0…20 mA Value of analog output 1, mA
0115 AO2[mA] 0…20 mA Value of analog output 2, mA
0116 Last Fault Fault Codes Last fault code of the drive.
0117 Previous Fault 1 Fault Codes Previous fault code of the drive.
0118 Previous Fault 2 Fault Codes Oldest fault code of the drive.
0119 Fault Time 1
0120 Fault Time 2
0121 Speed at Flt - RPM Speed at the time of the latest
fault.
0122 Freq at Flt - Hz Frequency at the time of the
latest fault.
0123 Voltage at Flt - V DC bus voltage at the time of
the latest fault.
➀ NOTE: Group 01 is read-only. Used for monitoring.
