53
Defaults
Group VFD Signals
Range Description
Single Synch- Multi- Constant Speed
01 Pump ronous Control Slave Control
0124 Current at Flt - A Motor current at the time of
the latest fault.
0125 Status at Flt - The drive status word at the
time of the latest fault.
0126 DI 6-1 At Fault 000…111 The drive digital input status at
the time of the latest fault.
0127 Drive On Time Hi - Days Drive “on - time in days.
0128 Drive On Time Lo - Hrs : Min : Sec Drive “on - time in hrs/min/secs.
Group Pump Signals
Range Description
Single Synch- Multi- Constant Speed
02 Pump ronous Control Slave Control
0201 Set Point 0…max scale Controller set point; unit
determined by parameter 1501.
0202 Actual 0…max scale Actual feedback; unit
determined by parameter 1501.
0203 Pump Speed 0 – 60 Hz Actual frequency of motor, Hz.
0204 Wire to Water 0…? Hp Overall hp includes pump,
Power motor and VFD.
0205 Set Point #1 0…max scale Set Point (reference) #1; unit
determined by parameter 1501.
0206 Set Point #2 0…max scale Set Point (reference) #2; unit
determined by parameter 1501.
0207 Energy Savings 0…65353 USD Calculated AV savings (option 1
or 2) since last reset. Savings are
compared to conventional
system ($). Re-settable by
parameter 26.05.
0208 Pump Number Stopped, Pump Actual pump number in multi-
1…Pump 4 pump control mode.
0209 Used Set Point 0…max scale Same value as in 0205 or 0206,
depending on which is in use.
Group Status Words
Range Description
Single Synch- Multi- Constant Speed
03 Pump ronous Control Slave Control
0301 FB CMD Word 1 — Low word of drive’s control word
0302 FB CMD Word 2 — High word of drive’s control word
0303 FB STS Word 1 — Low word of drive’s status word
0304 FB STS Word 2 — High word of drive’s status word
0305 Fault Word 1 — Fault word 1 of the drive
0306 Fault Word 2 — Fault word 2 of the drive
0307 Fault Word 3 — Fault word 3 of the drive
0308 Alarm Word 1 — Alarm word 1 of the drive
0309 Alarm Word 2 — Alarm word 2 of the drive
PARAMETER LISTINGS
