Analog Outputs
The Aquavar CPC has two 4-20 mA analog outputs as standard. These outputs may be
configured by the user to output from a selection of nine actual pump signals. Parameter
group 19 is used to configure these outputs. Analog Outputs are found on X1 Terminal Block,
# 2 and # 5 pins. Reference the terminal block diagram on pages 24-31 for detailed wiring
connections.
Parameter Name Value/Range Note(s)
19.01 AO 1 Not SEL (default) CONNECTS an ANALOG SIGNAL TO
Content Sel MOTOR FREQUENCY THE ANALOG OUTPUT. RANGE IS
MOTOR CURRENT 0-20mA input.
MOTOR POWER
MOTOR PROC VAR
MOTOR ENERGY
SAVNGS
19.06 AO 2 Not SEL (default) CONNECTS an ANALOG SIGNAL TO
Content Sel MOTOR FREQUENCY THE ANALOG OUTPUT. RANGE IS
MOTOR CURRENT 0 – 20mA input.
MOTOR POWER THIS IS THE DEFAULT PRESSURE
MOTOR PROC VAR TRANSDUCER INPUT. 4 – 20Ma.
MOTOR ENERGY
SAVNGS
21.01 REGULATION NORMAL (DEFAULT) SELECTS THE TYPE OF AQUAVAR
MODE INVERSE CONTROL AS THE ANALOG SIGNAL
RISES OR FALLS. SET TO INVERSE FOR
DECREASED MOTOR SPEED BASED ON
SUCTION LEVEL TRANSDUCER.
26.03 SAVINGS 0-65535 If ENERGY SAVNG is selected as an
SCALE Default – 10,000 output, this parameter must be set to
scale the signal. 4 mA = $0.00 and
20 mA equals this amount. For example
20 mA = $10,000.
Auto Restart
The Aquavar drive can be configured to start automatically following a power failure.
Changing the value to ON will enable auto-restart. Selecting OFF disables the auto-restart.
AUTO RESTART is also used with ERROR RESET for automatic restarts following a shutdown
due to a pump fault. AUTO RESTART will also restart the pump once a secondary protection
fault is reset.
Parameter Name Value/Range Note(s)
12.02 AUTO OFF When this is set to “ON “, the Aquavar
RESTART ON (DEFAULT) will automatically re-start after a power
failure or fault reset.
25.04 AR OVER- ENABLE Allows the drive to restart after a motor
CURRENT overcurrent error.
25.05 AR OVER- ENABLE Allows the drive to restart after an
VOLTAGE INPUT OVERVOLTAGE error.
25.06 AR UNDER- ENABLE Allows the drive to restart after an
VOLTAGE INPUT UNDERVOLTAGE error.
25.07 AR AI < ENABLE Allows the drive to restart after a
MIN transducer or analog signal loss.
FEATURES
