72
Defaults
Group
Modbus Range
Description
Single Synch- Multi- Constant Speed
32 Setup Pump ronous Control Slave Control
3210- EFB Parameters Meaning and values of these
3220 parameters depend on the
selected fieldbus protocol.
Group Motor
Range Description
Single Synch- Multi- Constant Speed
50 Control Pump ronous Control Slave Control
5001 Switching Freq 4, 8, 12 kHz Sets the switching frequency 4 4 4 4 4
for the drive. kHz kHz kHz kHz kHz
Group Maintenance
Range Description
Single Synch- Multi- Constant Speed
51 Triggers Pump ronous Control Slave Control
5101 Cooling Fan Trig 0.0…6553.5 Sets the trigger point for the 20 20 20 20 20
kh drive’s cooling fan counter.
0.0 = disabled
5102 Cooling Fan Act 0.0…6553.5 Defines the actual value of the
kh drive’s cooling fan counter. The
parameter is reset by writing
0.0 to it.
5103 Revolution Trig 0…65535 Sets the trigger point for the 32000 32000 32000 32000 32000
MRev motor’s accumulated revolutions
counter. 0.0 = disabled
5104 Revolution Act 0…65535 Defines the actual value of the
MRev motor’s accumulated revolutions
counter. The parameter is reset
by writing 0 to it.
5105 Run Time Trig 0.0…6553.5 Sets the trigger point for the 40 40 40 40 40
kh drive’s run time counter.
0.0 = disabled
5106 Run Time Act Displays actual run time.
Group Information
Range Description
Single Synch- Multi- Constant Speed
99 Pump ronous Control Slave Control
9901 FW Version AXXX hex Version of the firmware loaded
to the AV.
9902 Drive Rating XXXY Indicates the drive’s current and
voltage rating. The format is
XXXY, where:
XXX = The nominal current
rating in amps. If present an “A”
indicates the decimal point in
the rating for the current.
Y = The voltage rating of the
drive, where Y=2 indicates a
208…240 Volt rating and Y=4
indicates a 380…480 Volt
rating.
PARAMETER LISTINGS
