Alarms and events description and system troubleshooting guide 267
A
Commands from HMI
CPU Reinitialized Issued CPU is going to reboot, either because of a
modbus command, or an internal issue. The reason for the CPU reboot should be in
the event log. It will be one of the following:
CPU Reinitialize By Command, Note CPU
Internal Error 1, Note CPU Internal Error 2,
Note CPU Internal Error 3
CPU Reinitialize By Command CPU rebooted by Modbus reset relay
command The reset relay command is issued after new
firmware or a new option string is
downloaded to the CPU.
Breaker Open Command
Received CPU received a command via modbus to
open a breaker
Breaker Close Command
Received CPU received a command via modbus to
close a breaker
Breaker Trip Command
Received CPU received a command via modbus to trip
a breaker
Events Cleared By Command CPU received (via modbus) and executed a
command to clear its event log
Waveforms Cleared By
Command CPU received (via modbus) and executed a
command to clear its waveform capture
buffers
Waveform Capture Triggered By
Command CPU received (via modbus) and executed a
command to trigger a waveform capture
Fault Report Triggered By
Command CPU received (via modbus) and executed a
command to trigger a fault report
Date Time Updated CPU date and time changed
Demand Log Cleared All By
Command CPU received (via modbus) and executed a
command to reset the demand log for a
single breaker
Demand Log Cleared By
Command CPU received (via modbus) and executed a
command to reset the demand logs for all
breakers
Demand Reset By Command CPU received (via modbus) and executed a
command to reset the demand values for a
single breaker
Demand Reset All By Command CPU received (via modbus) and executed a
command to reset the demand values for all
breakers
Table A-2 Sequence of events description and troubleshooting guide
Event Description Notes and Troubleshooting tips
