Alarms and events 262
A
System OK Receiving Broadcast
From CPUB Messenger reports that it is receiving data
from CPU B
Test Mode Initiated From Test
Kit Messenger reports that test mode has been
initiated with the test kit
Test Mode Ended From Test Kit Messenger reports that test mode has ended
Protection Suspended GF From
Test Kit Messenger reports that ground fault
functionality is to be suspended
Protection Resumed GF From
Test Kit Messenger reports that ground fault
functionality can resume
Attention Compartment ID
Button Missing Messenger reports that it has detected that
the compartment ID button is missing See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Note Messngr Error 5 Compartment ID Button contains valid
configuration data, but EEPROM copy is bad See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Caution Check Compartment ID
Button Connection Messenger reports that the compartment ID
button connection needs to be checked See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Attention Messngr Error 1
Replace ASAP Messengr reports that its application flash
memory has a CRC error and should be
replaced Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention Messngr Error 2
Replace ASAP Messengr reports that its boot flash memory
has a CRC error and should be replaced Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention Messngr Error 3
Replace ASAP Messenger reports that it has an analog IOC
error and should be replaced Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention Messngr Error 4
Replace ASAP Messenger reports that it is not calibrated
and should be replaced Contact GE Post Sales Service (see How to
contact us on page 2 ).
CPU Status
Power On CPU has powered on
Discrete IO Test Mode Initiated Test mode for discrete I/O has been initiated
Discrete IO Test Mode Ended Test mode for discrete I/O has ended
All Metering and Protection
Disabled CPU is not performing any metering or
protection, either because it does not have a
valid option string or the firmware download
is invalid Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention Invalid PT Rating Volts
Suspended Programmed PT rating is not valid, no voltage
relays or metering will be done for
Messengers that use that Messenger as a
voltage source Contact GE Post Sales Service (see How to
contact us on page 2 ).
Table A-2 Sequence of events description and troubleshooting guide
Event Description Notes and Troubleshooting tips
