Monitoring system health
207
14
Table 14-1 contains descriptions and recommended actions for abnormal states (Red or Yellow)
on the Messenger Health screen. See
for additional information
on the event descriptions. Contact information for GE Post Sales Service is located at the end of
.
Table 14-1 descriptions and recommended actions for abnormal states
Status LED
Status
Description and Recommended Action
Messenger Hardware Health
Self test check
Red
Call GE Post Sales Service (see
).
Configuration
Red
Call GE Post Sales Service (see
).
NOTE: When this condition is detected, the following event is
logged: Caution Check Compartment ID Button Connection
Firmware
Red
Call GE Post Sales Service (see
).
Hardware
Red
call GE Post Sales Service (see
).
NOTE: When this condition is detected, one of the following
events is logged: Attention Messngr Error 3 Replace ASAP or
Attention Messngr Error 4 Replace ASAP
Compartment ID Button
Red
Call GE Post Sales Service (see
).
NOTE: When this condition is detected, the following events will
be logged: Caution Check Compartment ID Button Connection
and Note Messengr Error 5
Compartment ID Button
Yellow
Call GE Post Sales Service (see
).
NOTE: When this condition is detected, the following event will
be logged: Caution Check Compartment ID Button Connection
Messenger Settings Validation
Protection Settings in range
Red
This condition indicates that at least one of the settings in one of
the CPUs is invalid. Look for any of the following events in the
event log and verify the appropriate setting:
Attention Messngr Synch Disabld Bad Freq CPUA
Attention Messngr Synch Disabld Bad Freq CPUB
Invalid Setting IOC Mult CPUA Chng Rejected
Invalid Setting IOC Mult CPUB Chng Rejected
Invalid Setting ST From CPUA Change Rejected
Invalid Setting ST From CPUB Change Rejected
Invalid Setting GF From CPUA Change Rejected
Invalid Setting GF From CPUB Change Rejected
