Introduction to FlexLogic
173
11
ELEMENT:
High Resistance
Ground Fault Location
HRGF LOCATION FUNCTION 1 OFF
HRGF LOCATION FUNCTION 1 ON
HRGF Location Function 1 On pulses for the
contactor output - positive logic
HRGF Location Function 1 Off pulses for the
contactor output - negative logic
HRGF LOCATION 2…4
Same set of operands as shown for HRGF
Location 1
ELEMENT:
Instantaneous
Overcurrent
IOC 1 OP
IOC 1 DPO
Instantaneous Overcurrent 1 activated
Instantaneous Overcurrent 1 deactivated
IOC 2…30
Same set of operands as shown for IOC 1
ELEMENT:
Long Time
Overcurrent
LONG TIME 1 PKP
LONG TIME 1 OP
LONG TIME 1 DPO
Long Time Overcurrent 1 in pickup
Long Time Overcurrent 1 tripped breaker
Long Time Overcurrent 1 not in pickup
LONG TIME 2…30
Same set of operands as shown for LONG
TIME 1
ELEMENT:
Multi-Source Ground
Fault
MSGF ZONE 1 TRIP DPO
MSGF ZONE 1 ALARM DPO
MSGF ZONE 1 TRIP PKP
MSGF ZONE 1 ALARM PKP
MSGF ZONE 1 TRIP OP
MSGF ZONE 1 ALARM OP
MSGF ZONE 1 TRIP BACKUP OP
Multi-Source GF Zone 1 trip function not in
pickup
Multi-Source GF Zone 1 alarm function not
in pickup
Multi-Source GF Zone 1 trip function in
pickup
Multi-Source GF Zone 1alarm function in
pickup
Multi-Source GF Zone 1 trip function has
tripped breakers
Multi-Source GF Zone 1 alarm activated
Multi-Source GF Zone 1 trip backup function
has tripped backup breakers
MSGF ZONE 2…4
Same set of operands as shown for MSGF
ZONE 1
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE
OPERAND SYNTAX
OPERAND DESCRIPTION
