FlexLogic™ 174
11
ELEMENT:
Multi-Source Ground
Fault Summation Zone MSGF SUMMATION ZONE 1 TRIP DPO
MSGF SUMMATION ZONE 1 ALARM DPO
MSGF SUMMATION ZONE 1 TRIP PKP
MSGF SUMMATION ZONE 1 ALARM PKP
MSGF SUMMATION ZONE 1 TRIP OP
MSGF SUMMATION ZONE 1 ALARM OP
MSGF SUMMATION ZONE 1 TRIP
RESTRAINED
MSGF SUMMATION ZONE 1 ALARM
RESTRAINED
Multi-Source GF Summation Zone 1 trip
function not in pickup
Multi-Source GF Summation Zone 1 alarm
function not in pickup
Multi-Source GF Summation Zone 1 trip
function in pickup
Multi-Source GF Summation Zone 1 alarm
function in pickup
Multi-Source GF Summation Zone 1 trip
function has tripped breakers
Multi-Source GF Summation Zone 1 alarm
activated
Multi-Source GF Summation Zone 1 trip
function restrained
Multi-Source GF Summation Zone 1 alarm
function restrained
MSGF SUMMATION ZONE 2 Same set of operands as show above for
MSGF SUMMATION ZONE 1
ELEMENT:
Overvoltage MULTIPOINT REDUCED LET THRU
INITIATED System is operating in Reduced Energy
mode (topology 0)
ELEMENT:
Over frequency OVERFREQUENCY 1 ALARM PKP
OVERFREQUENCY 1 ALARM OP
OVERFREQUENCY 1 ALARM DPO
OVERFREQUENCY 1 TRIP PKP
OVERFREQUENCY 1 TRIP OP
OVERFREQUENCY 1 TRIP DPO
Overfrequency 1 alarm function in pickup
Overfrequency 1 alarm activated
Overfrequency 1 alarm function not in
pickup
Overfrequency 1 trip function in pickup
Overfrequency 1 relay function tripped
breaker
Overfrequency 1 trip function not in pickup
OVERFREQUENCY 2…30 Same set of operands as shown for
OVERFREQUENCY 1
ELEMENT:
Overvoltage OVERVOLTAGE 1 ALARM PKP
OVERVOLTAGE 1 ALARM OP
OVERVOLTAGE 1 ALARM DPO
OVERVOLTAGE 1 TRIP PKP
OVERVOLTAGE 1 TRIP OP
OVERVOLTAGE 1 TRIP DPO
Overvoltage 1 alarm function in pickup
Overvoltage 1 alarm activated
Overvoltage 1 alarm function not in pickup
Overvoltage 1 trip function in pickup
Overvoltage 1 relay function tripped
breaker
Overvoltage 1 trip function not in pickup
OVERVOLTAGE 2…30 Same set of operands as shown for
OVERVOLTAGE 1
ELEMENT:
Phase Loss PHASE LOSS 1 ALARM PKP
PHASE LOSS 1 ALARM OP
PHASE LOSS 1 ALARM DPO
PHASE LOSS 1 TRIP PKP
PHASE LOSS 1 TRIP OP
PHASE LOSS 1 TRIP DPO Phase Loss 1 alarm function in pickup
Phase Loss 1 alarm activated
Phase Loss 1 alarm function not in pickup
Phase Loss 1 trip function in pickup
Phase Loss 1 relay function tripped breaker
Phase Loss 1 trip function not in pickup
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION
