Introduction to FlexLogic 175
11
PHASE LOSS 2…30 Same set of operands as shown for PHASE
LOSS 1
ELEMENT:
PLC Inputs PLC INPUT 1...256 PLC Input x register is equal to 1
ELEMENT:
Power Reversal POWER REVERSAL 1 ALARM PKP
POWER REVERSAL 1 ALARM OP
POWER REVERSAL 1 ALARM DPO
POWER REVERSAL 1 TRIP PKP
POWER REVERSAL 1 TRIP OP
POWER REVERSAL 1 TRIP DPO
Reverse Power 1 alarm function in pickup
Reverse Power 1 alarm activated
Reverse Power 1 alarm function not in
pickup
Reverse Power 1 trip function in pickup
Reverse Power 1 relay function tripped
breaker
Reverse Power 1 trip function not in pickup
POWER REVERSAL 2…30 Same set of operands as shown for POWER
REVERSAL 1
ELEMENT:
Short Time
Overcurrent SHORT TIME 1 PKP
SHORT TIME 1 OP
SHORT TIME 1 DPO Short Time Overcurrent 1 in pickup
Short Time Overcurrent 1 tripped breaker
Short Time Overcurrent 1 not in pickup
SHORT TIME 2…30 Same set of operands as shown for SHORT
TIME 1
ELEMENT:
Synch Check SYNC CHECK 1 DEAD S OP
SYNC CHECK 1 DEAD S DPO
SYNC CHECK 1 SYNC OP
SYNC CHECK 1 SYNC DPO
SYNC CHECK 1 CLS OP
SYNC CHECK 1 CLS DPO
SYNC CHECK 1 V1 ABOVE MIN
SYNC CHECK 1 V1 BELOW MAX
SYNC CHECK 1 V2 ABOVE MIN
SYNC CHECK 1 V2 BELOW MAX
Synch Check 1 dead source has operated
Synch Check 1 dead source has dropped
out
Synch Check 1 in synchronization has
operated
Synch Check 1 in synchronization has
dropped out
Synch Check 1 close has operated
Synch Check 1 close has dropped out
Synch Check 1 V1 is above the minimum
live voltage
Synch Check 1 V1 is below the maximum
dead voltage
Synch Check 1 V2 is above the minimum
live voltage
Synch Check 1 V2 is below the maximum
dead voltage
SYNC 2…12 Same set of operands as show above for
SYNC CHECK 1
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION
