FlexLogic™ 172
11
ELEMENT:
Bus Differential BD ZONE 1 TRIP DPO
BD ZONE 1 ALARM DPO
BD ZONE 1 TRIP PKP
BD ZONE 1 ALARM PKP
BD ZONE 1 TRIP OP
BD ZONE 1 ALARM OP
BD ZONE 1 TRIP BACKUP OP
Bus Differential Zone 1 trip function not in
pickup
Bus Differential Zone 1 alarm function not in
pickup
Bus Differential Zone 1 trip function in
pickup
Bus Differential Zone 1 alarm function in
pickup
Bus Differential Zone 1 trip function has
tripped breakers
Bus Differential Zone 1 alarm activated
Bus Differential Zone 1 trip backup function
has tripped backup breakers
BD ZONE 2…4 Same set of operands as shown for BD
ZONE 1
ELEMENT:
Ground Fault GROUND FAULT 1 TRIP PKP
GROUND FAULT 1 ALARM PKP
GROUND FAULT 1 TRIP OP
GROUND FAULT 1 ALARM OP
GROUND FAULT 1 TRIP DPO
GROUND FAULT 1 ALARM DPO Ground Fault 1 trip in pickup
Ground Fault 1 alarm in pickup
Ground Fault 1 tripped breaker
Ground Fault 1 activated an alarm
Ground Fault 1 trip not in pickup
Ground Fault 1 alarm not in pickup
GROUND FAULT 2…30 Same set of operands as shown for
GROUND FAULT 1
ELEMENT:
High Current Relay HIGH CURRENT 1 PKP
HIGH CURRENT 1 OP
HIGH CURRENT 1 DPO High Current 1 in pickup
High Current 1 activated alarm
High Current 1 not in pickup
HIGH CURRENT 2…30 Same set of operands as shown for HIGH
CURRENT 1
ELEMENT:
High Current Trigger HIGH CURRENT 1 TRIGGER PKP
HIGH CURRENT 1 TRIGGER OP
HIGH CURRENT 1 TRIGGER DPO High Current 1 Trigger in pickup
High Current 1 Trigger activated alarm
High Current 1 Trigger not in pickup
HIGH CURRENT Trigger 2…30 Same set of operands as shown for HIGH
CURRENT Trigger 1
ELEMENT:
High Resistance
Ground Fault
Detection HRGF 1 PKP
HRGF 1 OP
HRGF 1 DPO HRGF 1 in pickup
HRGF 1 activated alarm
HRGF 1 not in pickup
HRGF 2…30 Same set of operands as shown for HRGF 1
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE OPERAND SYNTAX OPERAND DESCRIPTION
