Alarms and events
252
A
Relays - MSGF
Pickup Multi Source GF Zone
1…4
Multi source ground fault for zone 1…4 has
entered pickup
Dropout Multi Source GF Zone
1…4
Multi source ground fault for zone 1…4 has
dropped out of pickup
Breakers Trip Multi Source GF
Zone 1…4
Multi source ground fault for zone 1…4 has
operated and tripped the breakers
Breakers Trip Backup Multi
Source GF Zone 1…4
Multi source ground fault backup for zone
1…4 has operated and tripped the breakers
Alarm Pickup Multi Source GF
Zone 1…4
Alarm only multi source ground fault for zone
1…4 has entered pickup
Alarm Dropout Multi Source GF
Zone 1…4
Alarm only multi source ground fault for zone
1…4 has dropped out of pickup
Alarm Multi Source GF Zone 1…4 Alarm only multi source ground fault for zone
1…4 has operated
Pickup Multi Source GF Sum
Zone 1…2
Multi source ground fault for summation
zone 1…2 has entered pickup
Dropout Multi Source GF Sum
Zone 1…2
Multi source ground fault for summation
zone 1…2 has dropped out of pickup
Breaker Trip Multi Source GF
Sum Zone 1…2
Multi source ground fault for summation
zone 1…2 has operated and tripped the
breakers
Alarm Pickup Multi Source GF
Sum Zone 1…2
Alarm only multi source ground fault for
summation zone 1…2 has entered pickup
Alarm Dropout Multi Source GF
Sum Zone 1…2
Alarm only multi source ground fault for
summation zone 1…2 has dropped out of
pickup
Alarm Multi Source GF Sum
Zone 1…2
Alarm only multi source ground fault for
summation zone 1…2 has operated and
tripped the breakers
Protection Disabled Invalid Cfg
Multi Src GF
File that contains configuration information
for multi source ground fault is bad or
missing, all multi source ground fault
functions are disabled
Contact GE Post Sales Service (see
).
Table A-2 Sequence of events description and troubleshooting guide
Event
Description
Notes and Troubleshooting tips
