Appendix C

Grounding Reference

C.4 Check Point List

• Follow the single point grounding rule?

• Normal mode and common mode voltage?

• Separate the DC and AC ground?

• Reject the noise factor?

• The shield is connected correctly?

• Wire size is correct?

• Soldered connections are good?

• The terminal screw are tight?



































C-18

ADAM-5000/TCP User’s Manual
