Chapter 1

Understanding Your System

1-3 Technical specification of ADAM-

5000/TCP Series System

1-3-1 System

• CPU: ARM 32-bit RISC CPU

• Memory: 4 MB Flash RAM

• Operating System: Real-time O/S

• Timer BIOS: Yes

• I/O Capacity: 8 slots (ADAM-5000/TCP)

4 slots (ADAM-5000L/TCP)

• Status Indicator: Power (3.3V, 5V), CPU, Communication (Link,

Collide, 10/100 Mbps, Tx, Rx)

• CPU Power Consumption: 5.0W

• Reset Push Bottom: Yes

1-3-2 Ethernet Communication

• Ethernet: 10 BASE-T IEEE 802.3

100 BASE-TX IEEE 802.3u

• Wiring: UTP, category 5 or greater

• Bus Connection: RJ45 modular jack

• Comm. Protocol: Modbus/TCP

• Data Transfer Rate: Up to 100 Mbps

• Max Communication Distance: 100 meters

• Even Response Time: < 5 ms

• Data Stream Rate: 50 ms to 7 days

1-3-3 Serial Communication

• RS-485 signals: DATA +, DATA-

• Mode: Half duplex, multi-drop

• Connector: Screw terminal

• Transmission Speed: Up to 115.2 Kbps

• Max. Transmission Distance: 4000 feet (1220 m)
