Data Formats and I/O Ranges Appendix B
B.7 ADAM-5013 RTD Input Format and Ranges
Range
Code (hex)
Input Range
Description Data Formats
100 Ohms Platinum
Maximum
Specified
Signal
Minimum
Specified
Signal
Displayed
Resolution
20 RTD -100 to 100° C
a=0.00385
100 Ohms Platinum
21 RTD 0 to 100° C
a=0.00385
100 Ohms Platinum
22 RTD 0 to 200° C
a=0.00385
100 Ohms Platinum
23 RTD 0 to 600° C
a=0.00385
100 Ohms Platinum
24 RTD -100 to 100° C
a=0.00392
100 Ohms Platinum
25 RTD 0 to 100° C
a=0.00392
100 Ohms Platinum
26 RTD 0 to 200° C
a=0.00392
Engineering
Units
Engineering
Units
Engineering
Units
Engineering
Units
Engineering
Units
Engineering
Units
Engineering
Units
+100.00 -100.00 ±0.1° C
+100.00 +000.00 ±0.1° C
+200.00 +000.00 ±0.2° C
+600.00 +000.00 ±0.6° C
+100.00 -100.00 ±0.1° C
+100.00 +000.00 ±0.1° C
+200.00 +000.00 ±0.2° C
Note: See next page for table continuation.
ADAM-5000/TCP User’s Manual B-10
