Planning Your Application Program
$aaSiCjAhCSkCn
Name Set Alarm Connection
Chapter 6
Description Connects the High/Low alarm of the specified input
channel to the specified digital output in
the ad- dressed ADAM-5000/TCP system
Synta $aaSiCjAhCSkCn (cr)
$ is a delimiter character.
aa (range 00-FF) represents the 2-character hexadeci-
mal Modbus network address of an ADAM-5000/
TCP system.
SiCj identifies the desired slot i (i : 0 to 7) and the
desired analog input channel j (j : 0 to 7). AhC is the
Set Alarm Connection command.
h indicates alarm type and can have the value H =
High alarm, L = Low alarm SkCn identifies the
desired slot k (k : 0 to 7) and the desired digital
output point n (n : 0 to F). To discon- nect the digital
output, k and n should be set as ‘*’.
(cr) represents terminating character, carriage return
(0Dh)
Response !aa(cr) if the command was valid There is no
response if the system detects a syntax error or
communication error or if the specified ad- dress
does not exist.
! delimiter character indicating a valid command was
received.
aa represents the 2-character hexadecimal Modbus
network address of the corresponding ADAM-5000/
TCP system.
ADAM-5000/TCP User’s Manual 6-117
