Planning Your Application Program
$aaSiCjAhCSkCn
Name Set Alarm Connection
Chapter 6
Description Connect the High/Low alarm of the specified input
channel to the specified digital output in
the ad- dressed ADAM-5000/TCP system
Syntax $aaSiCjAhCSkCn(cr)
$ is a delimiter character.
aa (range 00-FF) represents the 2-character hexadeci-
mal Modbus network address of an ADAM-5000/
TCP system. SiCj identifies the desired slot i and the
desired chan- nel j .
AhC is the command for setting Alarm Connection
command.
h indicates alarm type and can have the value H =
High alarm, L = Low alarm
SkCn identifies the desired slot k and the desired
digital output point n (n : 0 to F). To disconnect the
digital output, k and n should be set as ‘*’.
(cr) represents terminating character, carriage return
(0Dh)
Response !aa(cr) if the command was valid There is no
response if the system detects a syntax error or
communication error or if the specified ad- dress
does not exist.
! delimiter character indicating a valid command was
received.
aa represents the 2-character hexadecimal Modbus
network address of the corresponding ADAM-5000/
TCP system.
ADAM-5000/TCP User’s Manual 6-177
