Data Formats and I/O Ranges
ADAM 5000 AI/AO Scaling
Appendix B
Module Type Range Low Range High Scale Low Scale High Data Format
-100 100 0 65535 U16B
0 100 0 65535 U16B
5013RTD
385(IEC)
395(JIS)
Ni
0 200 0 65535 U16B
0 600 0 65535 U16B
-100 100 0 65535 U16B
0 100 0 65535 U16B
0 200 0 65535 U16B
0 600 0 65535 U16B
-80 100 0 65535 U16B
0 100 0 65535 U16B
5017AI
5017H AI
5018 AI
5024 AO
mV -150 150 0 65535 U16B
mV -500 500 0 65535 U16B
V -1 1 0 65535 U16B
V -5 5 0 65535 U16B
V -10 10 0 65535 U16B
mA -20 20 0 65535 U16B
mV -500 500 0 4095 U12B
mV 0 500 0 4095 U12B
V -10 10 0 4095 U12B
V 0 10 0 4095 U12B
V -5 5 0 4095 U12B
V 0 5 0 4095 U12B
V -2.5 2.5 0 4095 U12B
V 0 2.5 0 4095 U12B
V -1 1 0 4095 U12B
V 0 1 0 4095 U12B
mA 4 20 0 4095 U12B
mA 0 20 0 4095 U12B
mV -15 15 0 65535 U16B
mV -50 50 0 65535 U16B
mV -100 100 0 65535 U16B
mV -500 500 0 65535 U16B
V -1 1 0 65535 U16B
V -2.5 2.5 0 65535 U16B
mA -20 20 0 65535 U16B
T/C(J) 0 760 0 65535 U16B
T/C(K) 0 1370 0 65535 U16B
T/C(T) -100 400 0 65535 U16B
T/C(E) 0 1000 0 65535 U16B
T/C(R) 500 1750 0 65535 U16B
T/C(S) 500 1750 0 65535 U16B
T/C(B) 500 1800 0 65535 U16B
V 0 10 0 4095 U12B
mA 4 20 0 4095 U12B
mA 0 20 0 4095 U12B
ADAM-5000/TCP User’s Manual B-12
