Selecting Your Hardware Components Chapter 2
‚ Calculate the Summary of the whole system’s power consumption.
For example, there are following items in your system.
ADAM-5000/TCP * 3 & ADAM-5024 * 4 & ADAM-5017 * 6 &
ADAM-5068 * 5 & ADAM-5050 * 5 & ADAM-5080 * 4
ò
The power consumption is:
5W * 3 + 2.9W * 4 + 1.25 * 6 + 1.8W * 5 + 1.2W * 5 + 1.5W * 4 = 55.1W
ƒ Selet a suitable power supply from Table2.4 or other comparable power
resource for system operation
Specification PWR-242 PWR-243 PWR-244
Input
Input Voltage 90~264 V
AC
85~132 V
AC
170~264 V
AC
100~240 V
AC
Input Frequency 47~63 Hz 47~63 Hz 47~63 Hz
25 A/110 V
AC
Input Current 1.2 A max. 1.4 A max. 50 A/220 V
AC
(Inrush current)
Short Protection Yes Yes Yes
Output
Output Voltage +24 V
DC
+24 V
DC
+24 V
DC
Output Current 2.1 A 3 A 4.2 A
Overload Protection Yes Yes Yes
General
Dimension
181 mm x 113 mm x
60 mm (L x W x H)
181 mm x 113 mm x
60 mm (L x W x H)
181 mm x 113 mm x
60 mm (L x W x H)
Operating Temperature 0~50º C (32~122º F) 0~50º C (32~122º F) 0~50º C (32~122º F)
DIN-rail Mountable Yes No No
Table2-4: Power Supply Specification Table
ADAM-5000/TCP User’s Manual 2-7
