Planning Your Application Program
$aaSiCjRhC
Name Read Alarm Connection
Chapter 6
Description Return the High/Low alarm limit output connection
of a specified input channel in the addressed ADAM-
5000/TCP system
Syntax $aaSiCjRhC(cr)
$ is a delimiter character.
aa (range 00-FF) represents the 2-character hexadeci-
mal Modbus network address of an ADAM-5000/
TCP system. SiCj identifies the desired slot i and the
desired chan- nel j. RhC is the command for reading
Alarm Connection. h indicates alarm type and can
have the value H = High alarm, L = Low alarm
(cr) represents terminating character, carriage return
(0Dh)
Response !aaSkCn(cr) if the command was valid There is no
response if the system detects a syntax error or
communication error or if the specified ad- dress
does not exist.
! delimiter character indicating a valid command was
received.
aa represents the 2-character hexadecimal Modbus
network address of the corresponding ADAM-5000/
TCP system.
SkCn identifies the desired slot k and the desired
digital output point n (n : 0 to F) to which the input
alarm is connected. If the values of k and n are ‘*’,
the analog input has no connection with a digital
output point.
ADAM-5000/TCP User’s Manual 6-179
