AT8xC5132
4173A–8051–08/02
Registers Table 20. AUXR1 Register
AUXR1 (S:A2h) – Auxiliary Register 1
Reset Value = XXXX 00X0b
7 6 5 4 3 2 1 0
- - ENBOOT - GF3 0 - DPS
Bit
Number
Bit
Mnemonic Description
7 - 6 -
Reserved
The values read from these Bits are indeterminate. Do not set these Bits.
5 ENBOOT
Enable Boot Flash
Set this bit to map the boot Flash in the code space between at addresses F000h
to FFFFh.
Clear this bit to disable boot Flash.
4 -
Reserved
The values read from this bit is indeterminate. Do not set this bit.
3 GF3
General Flag
This bit is a general-purpose user flag.
2 0
Always Zero
This bit is stuck to logic 0 to allow INC AUXR1 instruction without affecting GF3
flag.
1 - Reserved for Data Pointer Extension.
0 DPS
Data Pointer Select Bit
Set to select second data pointer: DPTR1.
Clear to select first data pointer: DPTR0.
