Timer/Counter Interrupt Flag
Register – TIFR
• Bit 7
–
TOV1: Timer/Counter1 Overflow Flag
The TOV1 is set (one) when an overflow occurs in Timer/Counter1. TOV1 is cleared by
hardware when executing the corresponding Interrupt Handling Vector. Alternatively,
TOV1 is cleared by writing a logical “1” to the Flag. When the I-bit in SREG, and TOIE1
( T i m e r /C o u n te r1 O ve r fl o w In te r ru p t En a b l e ), a n d T O V 1 a r e se t ( o ne ) , th e
Timer/Counter1 Overflow Interrupt is executed. In PWM mode, this bit is set when
Timer/Counter1 changes counting direction at $0000.
• Bit 6
–
OCF1A: Output Compare Flag 1A
The OCF1A bit is set (one) when a compare match occurs between the Timer/Counter1
and the data in OCR1A (Output Compare Register 1A). OCF1A is cleared by hardware
when executing the corresponding Interrupt Handling Vector. Alternatively, OCF1A is
cleared by writing a logical “1” to the Flag. When the I-bit in SREG and OCIE1A
(Timer/Counter1 Compare Match Interrupt A Enable) and OCF1A are set (one), the
Timer/Counter1 Compare A Match Interrupt is executed.
• Bit 5
–
OCF1B: Output Compare Flag 1B
The OCF1B bit is set (one) when a compare match occurs between the Timer/Counter1
and the data in OCR1B (Output Compare Register 1B). OCF1B is cleared by hardware
when executing the corresponding Interrupt Handling Vector. Alternatively, OCF1B is
cleared by writing a logical “1” to the Flag. When the I-bit in SREG and OCIE1B
(Timer/Counter1 Compare Match Interrupt B Enable) and OCF1B are set (one), the
Timer/Counter1 Compare B Match Interrupt is executed.
• Bit 4
–
TOV2: Timer/Counter2 Overflow Flag
The bit TOV2 is set (one) when an overflow occurs in Timer/Counter2. TOV2 is cleared
by hardware when executing the corresponding Interrupt Handling Vector. Alternatively,
TOV2 is cleared by writing a logical “1” to the Flag. When the SREG I-bit and TOIE2
( T i m e r / C o u n te r2 O v e r f l o w In t e rr u p t En a b l e ) a n d T O V 2 a re s e t ( o n e ) , t h e
Timer/Counter2 Overflow interrupt is executed.
• Bit 3 – ICF1: Input Capture Flag 1
T he ICF 1 bit is set (o ne) to fl ag an Inp ut C apture Event, i ndi cati ng that th e
Timer/Counter1 value has been transferred to the Input Capture Register (ICR1). ICF1
is cleared by hardware when executing the corresponding Interrupt Handling Vector.
Alternatively, ICF1 is cleared by writing a logical “1” to the Flag. When the SREG I-bit
and TICIE1 (Timer/Counter1 Input Capture Interrupt Enable) and ICF1 are set (one), the
Timer/Counter1 Capture Interrupt is executed.
• Bit 2 – OCF2: Output Compare Flag 2
The OCF2 bit is set (one) when a Compare Match occurs between the Timer/Counter2
and the data in OCR2 (Output Compare Register 2). OCF2 is cleared by hardware when
executing the corresponding Interrupt Handling Vector. Alternatively, OCF2 is cleared
by writing a logical “1” to the Flag. When the I-bit in SREG and OCIE2 (Timer/Counter2
Bit 7 6 5 4 3 2 1 0
$38 ($58) TOV1 OCF1A OCIFB TOV2 ICF1 OCF2 TOV0 OCF0 TIFR
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
