144
ATmega161(L)
1228C–AVR–08/02
Register Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
$3F ($5F) SREG I T H S V N Z C page 21
$3E ($5E) SPH SP15 SP14 SP13 SP12 SP11 SP10 SP9 SP8 page 22
$3D ($5D) SPL SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 page 22
$3C ($5C) Reserved
$3B ($5B) GIMSK INT1 INT0 INT2 - - - - - page 30
$3A ($5A) GIFR INTF1 INTF0 INTF2 page 31
$39 ($59) TIMSK TOIE1 OCIE1A OCIE1B TOIE2 TICIE1 OCIE2 TOIE0 OCIE0 page 31
$38 ($58) TIFR TOV1 OCF1A OCF1B TOV2 ICF1 OCFI2 TOV0 OCIF0 page 33
$37 ($57) SPMCR - - - - LBSET PGWRT PGERS SPMEN page 114
$36 ($56) EMCUCR SM0 SRL2 SRL1 SRL0 SRW01 SRW00 SRW11 ISC2 page 36
$35 ($55) MCUCR SRE SRW10 SE SM1 ISC11 ISC10 ISC01 ISC00 page 34
$34 ($54) MCUSR - - - - WDRF BORF EXTRF PORF page 29
$33 ($53) TCCR0 FOC0 PWM0 COM01 COM00 CTC0 CS02 CS01 CS00 page 42
$32 ($52) TCNT0 Timer/Counter0 Counter Register page 44
$31 ($51) OCR0 Timer/Counter0 Output Compare Register page 44
$30 ($50) SFIOR - - - - - - PSR2 PSR10 page 39
$2F ($4F) TCCR1A COM1A1 COM1A0 COM1B1 COM1B0 FOC1A FOC1B PWM11 PWM10 page 50
$2E ($4E) TCCR1B ICNC1 ICES1 - - CTC1 CS12 CS11 CS10 page 52
$2D ($4D) TCNT1H Timer/Counter1 - Counter Register High Byte page 53
$2C ($4C) TCNT1L Timer/Counter1 - Counter Register Low Byte page 53
$2B ($4B) OCR1AH Timer/Counter1 - Output Compare Register A High Byte page 54
$2A ($4A) OCR1AL Timer/Counter1 - Output Compare Register A Low Byte page 54
$29 ($49) OCR1BH Timer/Counter1 - Output Compare Register B High Byte page 54
$28 ($48) OCR1BL Timer/Counter1 - Output Compare Register B Low Byte page 54
$27 ($47) TCCR2 FOC2 PWM2 COM21 COM20 CTC2 CS22 CS21 CS20 page 42
$26 ($46) ASSR - - - - AS20 TCON2UB OCR2UB TCR2UB page 47
$25 ($45) ICR1H Timer/Counter1 - Input Capture Register High Byte page 54
$24 ($44) ICR1L Timer/Counter1 - Input Capture Register Low Byte page 54
$23 ($43) TCNT2 Timer/Counter2 Counter Register page 44
$22 ($42) OCR2 Timer/Counter2 Output Compare Register page 44
$21 ($41) WDTCR - - - WDTOE WDE WDP2 WDP1 WDP0 page 58
$20 ($40) UBRRHI UBRR1[11:8] UBRR0[11:8] page 78
$1F ($3F) EEARH - - - - - - - EEAR8 page 60
$1E ($3E) EEARL EEPROM Address Register Low Byte page 60
$1D ($3D) EEDR EEPROM Data Register page 60
$1C ($3C) EECR - - - - EERIE EEMWE EEWE EERE page 61
$1B ($3B) PORTA PORTA7 PORTA6 PORTA5 PORTA4 PORTA3 PORTA2 PORTA1 PORTA0 page 89
$1A ($3A) DDRA DDA7 DDA6 DDA5 DDA4 DDA3 DDA2 DDA1 DDA0 page 89
$19 ($39) PINA PINA7 PINA6 PINA5 PINA4 PINA3 PINA2 PINA1 PINA0 page 89
$18 ($38) PORTB PORTB7 PORTB6 PORTB5 PORTB4 PORTB3 PORTB2 PORTB1 PORTB0 page 91
$17 ($37) DDRB DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 page 91
$16 ($36) PINB PINB7 PINB6 PINB5 PINB4 PINB3 PINB2 PINB1 PINB0 page 91
$15 ($35) PORTC PORTC7 PORTC6 PORTC5 PORTC4 PORTC3 PORTC2 PORTC1 PORTC0 page 98
$14 ($34) DDRC DDC7 DDC6 DDC5 DDC4 DDC3 DDC2 DDC1 DDC0 page 98
$13 ($33) PINC PINC7 PINC6 PINC5 PINC4 PINC3 PINC2 PINC1 PINC0 page 98
$12 ($32) PORTD PORTD7 PORTD6 PORTD5 PORTD4 PORTD3 PORTD2 PORTD1 PORTD0 page 100
$11 ($31) DDRD DDD7 DDD6 DDD5 DDD4 DDD3 DDD2 DDD1 DDD0 page 100
$10 ($30) PIND PIND7 PIND6 PIND5 PIND4 PIND3 PIND2 PIND1 PIND0 page 100
$0F ($2F) SPDR SPI Data Register page 68
$0E ($2E) SPSR SPIF WCOL - - - - - SPI2X page 67
$0D ($2D) SPCR SPIE SPE DORD MSTR CPOL CPHA SPR1 SPR0 page 66
$0C ($2C) UDR0 UART0 I/O Data Register page 73
$0B ($2B) UCSR0A RXC0 TXC0 UDRE0 FE0 OR0 - U2X0 MPCM0 page 73
$0A ($2A) UCSR0B RXCIE0 TXCIE0 UDRIE0 RXEN0 TXEN0 CHR90 RXB80 TXB80 page 75
$09 ($29) UBRR0 UART0 Baud Rate Register page 78
$08 ($28) ACSR ACD AINBG ACO ACI ACIE ACIC ACIS1 ACIS0 page 81
$07 ($27) PORTE - - - - - PORTE2 PORTE1 PORTE0 page 106
$06 ($26) DDRE - - - - - DDE2 DDE1 DDE0 page 106
$05 ($25) PINE - - - - - PINE2 PINE1 PINE0 page 106
$04 ($24) Reserved
$03 ($23) UDR1 UART1 I/O Data Register page 73
$02 ($22) UCSR1A RXC1 TXC1 UDRE1 FE1 OR1 - U2X1 MPCM1 page 75
$01 ($21) UCSR1B RXCIE1 TXCIE1 UDRIE1 RXEN1 TXEN1 CHR91 RXB81 TXB81 page 73
$00 ($20) UBRR1 UART1 Baud Rate Register page 78
