133
ATmega161(L)
1228C–AVR–08/02
External Data Memory Timing
Notes: 1. This assumes 50% clock duty cycle. The half period is actually the high time of the external clock, XTAL1.
2. This assumes 50% clock duty cycle. The half period is actually the low time of the external clock, XTAL1.
Table 51. External Data Memory Characteristics, 4.0 - 5.5 Volts, No Wait State
Symbol Parameter
8 MHz Oscillator Variable Oscillator
Unit Min Max Min Max
0 1/t
CLCL
Oscillator Frequency 0.0 8.0 MHz
1 t
LHLL
ALE Pulse Width 95 1.0t
CLCL
-30 ns
2 t
AVLL
Address Valid A to ALE Low 22.5 0.5t
CLCL
-40 (1) ns
3a t
LLAX_ST
Address Hold After ALE Low,
write access
10 10 ns
3b t
LLAX_LD
Address Hold after ALE Low,
read access
15 15 ns
4 t
AVLLC
Address Valid C to ALE Low 22.5 0.5t
CLCL
-40 (1) ns
5 t
AVRL
Address Valid to RD Low 95 1.0t
CLCL
-30 ns
6 t
AVWL
Address Valid to WR Low 95 1.0t
CLCL
-30 ns
7 t
LLWL
ALE Low to WR Low 42.5 145 0.5t
CLCL
-20 (2) 0.5t
CLCL
+20 (2) ns
8 t
LLRL
ALE Low to RD Low 42.5 145 0.5t
CLCL
-20 (2) 0.5t
CLCL
+20 (2) ns
9 t
DVRH
Data Setup to RD High 60 60 ns
10 t
RLDV
Read Low to Data Valid 65 65 ns
11 t
RHDX
Data Hold After RD High 0 0 ns
12 t
RLRH
RD Pulse Width 105 1.0t
CLCL
-20 ns
13 t
DVWL
Data Setup to WR Low 27.5 0.5t
CLCL
-35 (1) ns
14 t
WHDX
Data Hold After WR High 27.5 0.5t
CLCL
-35 (1) ns
15 t
DVWH
Data Valid to WR High 95 1.0t
CLCL
-30 ns
16 t
WLWH
WR Pulse Width 105 1.0t
CLCL
-20 ns
Table 52. External Data Memory Characteristics, 4.0 - 5.5 Volts, 1 Cycle Wait State
Symbol Parameter
8 MHz Oscillator Variable Oscillator
Unit Min Max Min Max
0 1/t
CLCL
Oscillator Frequency 0.0 8.0 MHz
10 t
RLDV
Read Low to Data Valid 185 2.0t
CLCL
-65 ns
12 t
RLRH
RD Pulse Width 230 2.0t
CLCL
-20 ns
15 t
DVWH
Data Valid to WR High 220 2.0t
CLCL
-30 ns
16 t
WLWH
WR Pulse Width 230 2.0t
CLCL
-20 ns
